System type:12"  2-way active filter

Power Rating RMS: 800W

Power Rating MAX: 1600W

Frequency response(-10dB): 48Hz - 20KHz

MAX SPL: 125dB / 131dB(Peak)

LF Driver: 12" woofer, 3" VC

HF Driver: 5.3", 2" VC Titanium

Amplifier type: Class-D Bi-amp

Input connectors: XLR or 1/4" Jack

Output connectors: XLR Balanced

Cooling system: Passive radiator

Functions: DSP setup, RS485 Network

Power Voltage: AC100V - AC240V 50/60Hz

Enclosure:  plywood

Dimensions(WxDxH): 380x395x645mm

Net weight: 24Kg

Qty per container 20’/40’/40’HC: 200/415/500
